More function:
*Metal Case ip67
* Build in Mic
* Support SD card
* Multil-Language
4/8 MP WDR IR Turret Network Camera
> 4/8 Megapixel progressive CMOS
> H.265 & H.264 dual-stream encoding
> 4MP 2560*1440@25fps
> WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> Micro SD card slot, up to 256GB
> Max IR LEDs Length 30m
> IP67, PoE
> English, Traditional, Italian, Spanish, Japanese, Russian, French, German, Portuguese, Turkish, Polish, Romanian, Hungary, North Korea, Czech Republic, Netherlands, Ukraine, Vietnam, Arabia, Spain (Europe), Indonesia
High quality imaging Day&Night Vision
Super HD 4MP (2560 1440)@25/30 fps, Built-in IR LED.Max IR LEDs Length 30M
Built-in microphone for real-time audio security /Supports max. 256 GB Micro SD card
Water and dust resistant (IP67)
Waterproof metal case,widely used for indoor & outdoor,Camera Working Temperature: -40C to +60C (-40F to +140F)/less than ≤ 95%
Easy access via free Mobile Device APP & PC Software
When you go outside,you not needworry about your property security. you can remote view live video simultaneously at anytime, anywhere with wifi/4G/5G on smartphone/iPad/PC. With the free app "DMSS" users can access footage via their smart device (IOS/Android) or computer (Windows) software: SmartPass. Watch live streams and view playbacks instantly
1.Camera
Image Sensor : 4/8 Megapixel progressive scan CMOS
Effective Pixels : 4MP 2560*1440@25fps,
Scanning System : Progressive
Electronic Shutter Speed : Auto/Manual, 1/3~1/100000s
Minimum Illumination : 0.002Lux( Color), 0.0002( black/white), 0Lux(IR on)
S/N Ratio : More than 56dB
IR Distance : Distance up to 50m
IR On/Off Control : Auto/ Manual
2.Lens
Lens Type : Fixed
Mount Type : Board-in
Focal Length : 2.8mm
Max. Aperture : F1.6
Angle of View : 2.8mm : H : 99 V : 72
Focus Control : Fixed
Close Focus Distance : 0.8m
3.Intelligence
IVS : Tripwire, Intrusion, Object Abandoned/Missing
4.Video
Compression : H.265/H.264/MJPEG
Streaming Capability : 3 Streams
Resolution : 6M(30722048)/5M(3072x1728)
Frame Rate : "Main Stream : 6M(1~25fps)
Bit Rate : 32Kbps~10240Kbps
Day/Night : Auto(ICR) / Color / B/W
BLC Mode : BLC / HLC / WDR(120dB)
White Balance : Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control : Auto/Manual
Noise Reduction : 3D DNR
Motion Detetion : Off / On (4 Zone, Rectangle)
Region of Interest : Off / On (4 Zone)
Mirror : Off / On
Privacy Masking : Off / On (4 Area, Rectangle)
5.Audio
Compression : G.711a/ G.711Mu/ AAC/ G.726
6.Network
Ethernet : RJ-45 (10/100Base-T)
Protocol :HTTP;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP;FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;SNMP;QoS;UPnP;NTP Interoperability : ONVIF, PSIA, CGI;
Max. User Access : 20 Users
Edge Storage : NAS Local PC for instant recording
Web Viewer : IE, Chrome, Firefox, Safari
Management Software : Smart PSS, DSS, Easy4ip
Smart Phone : IOS, Android
7.Interface
Video Interface : N/A
Audio Interface : Built-in Mic
RS485 : N/A
Alarm : N/A
8.Electrical
Power Supply : DC12V, PoE (802.3af)(Class 0)
Power Consumption : <4.8W
9.Environmental
Operating Conditions : -30 C ~ +60 C (-22 F ~ +140 F) / Less than 95% RH
Strorage Conditions : -30 C ~ +60 C (-22 F ~ +140 F) / Less than 95% RH
Ingress Protection : IP67
10.Construction
Casing : Metal
Dimensions : Φ106mm93.7mm (4.17'3.69')
Net Weight : 0.47Kg (1.04lb)
Gross Weight : 0.65Kg (1.43lb)
What in Box :
> 4MP OR 8MP IP CAMERA * 1
> Screw bag * 1
> Waterproof Accessories for IP Camera * 1
Question: What kind of warranty does the camera offer?
Answer: we support 1 years warranty.
Question: How default IP and login pass for connection to Camera?
Answer: 192.168.1.108. User name is admin Password is left blank. You can set it once you're logged in.
Question: how do you factory reset?
Answer: it have reset buttom. press 15s.
Question: both have SD card Slot?
Answer: Yes Build SD card Slot
