ANNKE 16CH NVR Security Camera System Smart Dual Light with 10pcs H.265+ Waterproof Motion Detection CCTV CameraSurveillance Kit
Key features
NVR:
· Live view, recording&playback up to 12 MP resolution
· Up to 8 channel IP cameras can be connected with built-in PoE inputs
· Advanced H.265+ Video Compression
· Supports iPhone, iPad, Android mobile remote monitoring
· Connectable to the third-party network cameras
· HDMI Video output at up to 4K (40960 × 2160) resolution
· Annke Vision for easy remote view
· Support 4-ch Human and vehicle targets detection
Camera
★ 3K IR Network Camera with 16:9 image scale
★ 2.8mm lens brings everything back to life
★ Efficient H.265+ compression technology
★ Motion detection 2.0 with human & Vehicle Detection
★ Smart Dual-Light: advanced technology with long range
★ Clear day and night vision with 3D DNR and 120DB WDR
★ Built-in microphone for real-time audio security
★ Support on-board storage up to 512 GB (SD card slot)
★ IP67 Dust and Waterproof Rating
★ Support PoE &DC12V
[Capture Clear Night Detail by Smart Dual Light]
Default smart dual light mode in night, the camera can clearly find the target at night by infrared light, If there is a moving target, the white light will start, infrared off, so as to obtain a clear color image.
In addition, you can also choose full infrared or full white light mode. Infrared fill light is up to 30 m, up to 20 m white light distance for bright night imaging.
[Ultra-clear Video in 3K with 16:9 Image Scale]
With 1/3" Progressive Scan BSI CMOS sensor, this camera can deliver amazing 3K (3072x1728@20fps) videos with all the subtle details that are true to life. 16:9 aspect ratio effect is better than traditional 4:3, more suitable for mainstream display ratio.
[Smart Human & Vehicle Detection, Brings 99% Accurate Alerts]
Using an intelligent algorithm based on a deep learning platform, the motion detection 2.0 camera will detect people and vehicle, which helps reduce 99% unwanted motion alerts triggered by animals, or random inanimate objects.
[H.265+/H.265 to Save Storage Space]
The new generation of H.265+/H.265 video coding technology can save bandwidth while providing clear and delicate images.
H.265 videos require only 50% of the storage space required for traditional H.264 videos at the same pixel and data rate, so you save half the storage space.
[4 Top-of-the-Line Image Enhancement Technologies]
The IP camera adopts 4 incredible image enhancement technologies – 120 dB true WDR, 3D DNR, BLC & HLC – to provide the splendid 3K Super HD clarity. So, whether you view the live stream by day or by moonlight, you'll get a new level of details and colors that wasn't possible before.
[IP67 Weatherproof – Extreme Weather Capabilities]
IP67 rated, the camera is fully weatherproof & can be immersed in 1 m of water for 30 mins. It continues to operate in extreme temperatures as low as -22 °F (-30 °C). Torrential downpours, heavy winds, freezing snow storms, the camera braves them all.
4PCS
8PCS
NVR:
Video & Audio | Decoding Format | H.264+/H.264/H.265/H.265+ |
IP Video Input | 8CH PoE | |
Video Output | HDMI up to 4K (4096 × 2160), VGA up to 1080p(1920 × 1080) | |
Audio Input/Output | 1/1 RCA | |
Incoming/outgoing Bandwidth | 80/80 Mbps | |
Max Recording Resolution | Up to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) | |
Max Playback Resolution | Up to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) | |
Max Playback Channel | 8CH | |
Max Playback Capacity | 1-ch@12 MP(4096 X 3072) (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps) | |
Hard Drive | HDD | 1 SATA Interface |
HDD Capacity | Up to 8 TB Capacity | |
External Interface | Network Interface | 1, RJ-45 10/100Mbps self-adaptive Ethernet interface |
PoE | 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface, IEEE 802.3 af/at | |
USB interface | USB 2.0*2 | |
Smart Function | Deep learning | 8-ch Human and vehicle targets detection(Need IP camera support) |
4-ch Human and vehicle targets detection(IP camera does not need to support this function but the resolution cannot exceed 4MP) | ||
Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting | |
General | Operating Power | DC 48 V |
Power Consumption | ≤10 W (Without HDD and PoE) | |
PoE: Max 25.5 W for Single Port | ||
Working Temperature | 14 °F ~ 131 °F/-10 °C ~+55 °C | |
Dimensions (W X H X D) | 12.4' X 9.4' X 1.9'/315 X 240 X 48 mm | |
Weight (Without Hard Disk) | 2.2 lbs/1 kg |
Camera:
Camera | Image Sensor | 1/3" Progressive Scan CMOS |
Max resolution | 3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display | |
Main Stream | 50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720) | |
Substream | 50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360) | |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 | |
Video Bitrate | 32 Kbps - 6 Mbps | |
Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC | |
Audio Input | Built-in Microphone, record with audio | |
Lens | 2.8 mm | |
Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR | |
Angle of View | Horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114° | |
Supplement Light Type | Smart Dual-Light, IR, White Light | |
Supplement Light Range | Up to 30 m | |
Motion detection 2.0 | Supoort, include Human & Vehicle detection | |
Image Enhancement | BLC, HLC, 3D DNR | |
Wide Dynamic Range | 120 dB WDR | |
Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP | |
API | Open Network Video Interface Version 18.12 | |
Region of Interest (ROI) | 1 fixed region for main stream | |
Privacy Mask | 4 programmable polygon privacy masks | |
General Function | Mirror,rotate,password protection, remote access | |
Ethernet | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
General | Housing | Metal & Plastic |
Color | White | |
Storage | Built-in microSD/SDHC/SDXC Slot, up to 512 GB | |
Hardware Reset | Yes | |
Operating Power | DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | |
Operating Temperature | -22 °F – 140 °F/-30 °C – 60 °C | |
Indoor/Outdoor Use | Indoor/Outdoor | |
Interface Protection | IP67 | |
Dimension (L X W X H) | Ø110 mm × 89.2 mm (Ø4.3" × 3.5") | |
Weight | Approx. 340 g (0.7 lb.) |
