ANNKE 4K Camera Security Panoramic Dual Lens Human Detect Auto Track Two Way Audio IP Camera Dual Lens Poe 180° Wide View Angle

IP Camera

Camera

Image sensor

2×1/2.5" Progressive Scan CMOS

Max resolution

4K(4096 × 1840), 20: 9 picture ratio

Main Stream

50 Hz: 20 fps (4096 × 1840)
60 Hz: 20 fps (4096 × 1840)

Sub Stream

50 Hz: 20 fps(1200 × 536, 960 × 432)
60 Hz: 20 fps(1200 × 536, 960 × 432)

Video compression

Main Stream: H.265+/H.265/H.264+/H.264
Sub Stream: H.265/H.264/MJPEG

Video Bit Rate

32 Kbps to 16 Mbps

Built-in Microphone

Built-in Microphone, record with audio

Audio Compression

G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3

Built-in Speaker

Yes, max. sound pressure: 10 cm: 95 dB

Lens

Dual lens: 2.8 mm

Min. Illumination

Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR

Angle of View

Horizontal FOV: 180° ± 10°, Vertical FOV: 81° ± 10°

Supplement Light Type

White light, IR

Supplement Light Range

White light up to 20 m, IR light up to 30m

Motion detection 2.0

Supoort, include Human & Vehicle detection

Image Parameters Switch

Yes

Image Enhancement

BLC, HLC, 3D DNR

Wide Dynamic Range

120dB WDR

Network Protocols

TCP/IP,ICMP,HTTP,HTTPS,802.1x,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,UPnP,SMTP,IGMP,QoS,IPv6,UDP,Bonjour,SSL/TLS,WebSocket, SNMP

API

Open Network Video Interface Version 19.12

Basic Event

Motion detection (support human and vehicle detection), video tampering, exception detection

Smart Event

Line crossing detection, intrusion detection, region entrance detection, region exiting detection(support human and vehicle detection)

Audio Alarm

Support(Parameters adjustable,support custom audio, can be triggered from APP)

Region of Interest (ROI)

1 fixed region for main stream

General Function

IP Address Filter

General

Housing

Metal&Plastic, White color

Operating Power

PoE (802.3af), 12 VDC ± 25%,Ø 5.5 mm coaxial power plug

Ethernet Interface

1 RJ45 10 M/100 M self-adaptive Ethernet port

Storage

Built-in micro SD/SDHC/SDXC slot, up to 256 GB, support NAS, NVR

DC12V output

DC12 V, 100 mA output

Audio input/output

1 input (line in),1 output (line out)

Alarm nput/output

1 input, 1 output (max. 24 VDC, 1 A)

Hardware Reset

Yes

Operating Temperature

-22 °F – 140 °F /-30 °C – 60 °C

Indoor/Outdoor

Indoor/Outdoor

Weatherproof Rating

IP66

Dimension (L x W x H)

138.1 × 101.1 × 120.4 mm

Weight

Approx. 600 g (1.32 lb.)
