ANNKE 4K Duo Dual Lens Outdoor Security Camera POE AI Human Detect Full Color Night Vision Video Surveillance Security Camera
6MP I51DW camera only work with "ANNKE" NVR and should be updated to the latest version.
(Please confirm if your NVR is the latest version before you purchase this camera.)
IP Camera | ||
Camera | Image sensor | 2×1/1.8" Progressive Scan CMOS |
Main Stream | When WDR is On:50 Hz: 12.5 fps (5120 × 1440) 60 Hz: 15 fps (5120 × 1440) | |
Sub Stream | When WDR is On:50 Hz: 12.5 fps (1920 × 536, 960 × 272)60 Hz: 15 fps (1920 × 536, 960 × 272) | |
Video compression | H.265+/H.265/H.264+/H.264 | |
Video Bit Rate | 32 Kbps to 16 Mbps | |
Built-in Microphone | Yes, support environment noise filtering | |
Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC | |
Built-in Speaker | Yes, max. sound pressure: 10 cm: 95 dB | |
Lens | Dual lens: 4 mm | |
Min. Illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light | |
Angle of View | Horizontal FOV: 180° ± 10°, Vertical FOV: 44° | |
DORI | 4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m | |
Supplement Light | Yellow warm light | |
Supplement Light Range | Up to 40 m | |
Image Parameters Switch | Yes | |
Image Enhancement | BLC, HLC, 3D DNR | |
Wide Dynamic Range | 130dB WDR | |
Network Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, | |
Basic Event | Motion detection (support human and vehicle detection),video tampering | |
Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting detection, scene change detection,(support human and vehicle detection) | |
Flashing Light alarm | Support(Parameters adjustable,can be triggered from APP) | |
Audio Alarm | Support(Parameters adjustable,support custom audio, can be triggered from APP) | |
General | Housing | Metal, White color |
Operating Power | PoE (802.3af), 12 VDC ± 25%,Ø 5.5 mm coaxial power plug | |
Storage | Built-in micro SD/SDHC/SDXC slot, up to 256 GB, support NAS, NVR, | |
Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
Audio input/output | 1 input (line in),1 output (line out) | |
Alarm nput/output | 1 input, 1 output (max. 24 VDC, 1 A) | |
Hardware Reset | Yes | |
Operating Temperature | -22 °F – 140 °F /-30 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP67 | |
Dimension (L x W x H) | Ø 155 mm × 155.3 mm (Ø 6.1" × 6.1") | |
Weight | Approx. 1110 g (2.4 lb.) | |
Key features
★ 6 MP Panoramic 180°Fixed Bullet Network Camera
★ One image that presents all the scenes covered by the camera
★ Efficient H.265+ compression technology
★ Clear imaging against strong back light due to 120 dB WDR technology
★ Focus on human and vehicle classification based on deep learning
★ Audio alarm to warn intruders off
★ White light up to 20 m, IR light up to 30m
★ Water and dust resistant (IP66)
★ Support 256 GB TF storage space
★ Two way audio
Packaging Contents
1 X IP Camera
1 X Metal Bracket
1 X 1m Network cable
1 X Waterproof connector
1 X Mounting Screws Bag
1 X User's Manual For Camera
IP Camera | ||
Camera | Image sensor | 2×1/2.5" Progressive Scan CMOS |
Main Stream | 50 Hz: 20 fps (3632 × 1632) | |
Sub Stream | 50 Hz: 20 fps(1200 × 536, 960 × 432) | |
Video compression | Main Stream: H.265+/H.265/H.264+/H.264 | |
Video Bit Rate | 32 Kbps to 16 Mbps | |
Built-in Microphone | Yes, support environment noise filtering | |
Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3 | |
Built-in Speaker | Yes, max. sound pressure: 10 cm: 95 dB | |
Lens | Dual lens: 2.8 mm | |
Min. Illumination | Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR | |
Angle of View | Horizontal FOV: 180° ± 10°, Vertical FOV: 81° ± 10° | |
Supplement Light | White light + IR | |
Supplement Light Range | White light up to 20 m, IR light up to 30m | |
Image Parameters Switch | Yes | |
Image Enhancement | BLC, HLC, 3D DNR | |
Wide Dynamic Range | 120dB WDR | |
Network Protocols | TCP/IP,ICMP,HTTP,HTTPS,802.1x,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,UPnP,SMTP,IGMP,QoS,IPv6,UDP,Bonjour,SSL/TLS,WebSocket,Onvif | |
Basic Event | Motion detection (support human and vehicle detection), video tampering | |
Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting detection(support human and vehicle detection) | |
Audio Alarm | Support(Parameters adjustable,support custom audio, can be triggered from APP) | |
Compatible NVR | ANNKE latest version NVR: N48PBB-V2, N44PAM, N48PAW-V2, N46PCK-V2, N931BB, N88PCH, N96PBD, please confirm if your NVR is the latest version before you purchase this camera | |
General | Housing | Metal&Plastic, White color |
Operating Power | PoE (802.3af), 12 VDC ± 25%,Ø 5.5 mm coaxial power plug | |
Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
Storage | Built-in micro SD/SDHC/SDXC slot, up to 256 GB, support NAS, NVR | |
DC12V output | DC12 V, 100 mA output | |
Audio input/output | 1 input (line in),1 output (line out) | |
Alarm nput/output | 1 input, 1 output (max. 24 VDC, 1 A) | |
Hardware Reset | Yes | |
Operating Temperature | -22 °F – 140 °F /-30 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP66 | |
Dimension (L x W x H) | 103.6 × 76 × 193.4 mm | |
Weight | Approx. 600 g (1.32 lb.) | |
