ANNKE 4K Ultra HD 8CH DVR H.265 CCTV Camera Security System 4PCS 8MP IP67 Weaterproof Outdoor 8MP Camera Video Surveillance
ANNKE 4K Ultra HD 8CH DVR H.265 CCTV Camera Security System 4PCS IP67 Weaterproof Outdoor 8MP Camera Metal Video Surveillance
DVR Key Features:
· 4K(8MP) high definition live viewing
· 4K(8MP) recording & playback
· Deep learning-based motion detection 2.0 for all analog channels
· Deep learning-based perimeter protection
· Advanced H.265+ Video Compression
· Aduio via coaxial cable
· Support TVI/AHD/CVI/CVBS/IPC input. 5 in 1
· Supports iPhone, iPad, Android mobile remote monitoring
Camera Key Features:
Note:
1.If you don't purchase a hard disk,you can't record and review the video.
DVR | ||
Video & Audio | Video Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
Video Input | 8CH Analog HD/Analog + 4CH (up to 12-ch) IP (Enhanced IP mode on: | |
Video Output | VGA up to 1080p/60 Hz; HDMI up to 4K (3840 × 2160)/30 Hz | |
Audio Input/Output | Input: 1-ch, RCA (2.0 Vp-p, 1 KΩ)/8-ch via coaxial cable | |
Supported Camera Types | Support HD TVI Input: 8 MP@15 fps, 5 MP@20 fps, 3K@20 fps, 4 | |
Analog HD Playback Resolution | 4K@8 fps/5MP@12 fps/4MP@15 fps/3MP@18 fps | |
IP Camera Input | 4-CH (up to 12-ch) | |
IPC Recording Resolution | Up to 8MP | |
IPC Playback Resolution | Up to 8MP | |
Max Playback Channel | 8CH | |
Motion Detection 2.0 | Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights. | |
Smart event | Line crossing & Intrusion Detection | |
ONVIF | Support | |
Hard Drive | HDD | 1 SATA Interface |
HDD Capacity | Up to 10 TB Capacity | |
External Interface | Network Interface | RJ45 X1(10/100 M/1000 M self-adaptive Ethernet interface) |
RS485 | Support | |
USB | USB 2.0 X1 + USB 3.0 X 1 | |
General | Working Temperature | 14 °F – 131 °F/-10 °C – 55 °C |
Dimensions (W X H X D) | 315 X 242 X 45 mm | |
Weight (Without Hard Disk) | ≤2 kg (4.4 lbs.) (Without HDD) | |
Analog HD Camera | ||
Image Sensor | 8.29MP Sony STARVIS IMX274CMOSImage Sensor | |
Camera | Video Resolution | 3840(H) X 2160(V) |
Signal System | PAL/NTSC | |
Frame Rate | 8MP@12.5 fps, 8MP@15 fps, 4MP@25 fps, 4MP@30 fps, 2MP@25 fps, | |
Lens | 2.8 mm | |
Min. Illumination | 0.01 Lux@(F1.2, AGC On), 0 Lux with IR | |
Angle of View | 102.2° | |
Number of Infrared LEDs | 2 | |
OSD Menu | Yes | |
Night Vision Distance | Up to 100 ft/30 m | |
DNR | 2D DNR | |
Wide Dynamic Range | Digital WDR | |
IR-Cut Filter | Yes | |
Video Output | HD BNC X1 | |
General | Housing | Plastic |
Color | White | |
Operating Power | DC 12 V | |
Operating Temperature | -40 °F – 140 °F/-40 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP67 | |
Dimension (L X W X H) | 58 mm X 61 mm X 159.8 mm (2.28" X 2.40" X 6.42") | |
Weight | 0.46 lb./ 210 g | |
