ANNKE 8CH 8MP Ultra HD PoE Network Video Security System 4K H.265 Surveillance NVR 8MP H800 Audio in POE CCTV Bullet Cameras

IP Camera Specifications (I91DL)

Camera

Image Sensor

1/2.4" Progressive Scan CMOS

Max resolution

3840*2160(8MP)

Main Stream

50 Hz: 12.5fps@3840*2160, 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 15fps@3840*2160, 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

Substream

50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360)

Video Compression

Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG

Video Bitrate

32 Kbps - 16 Mbps

Audio Compression

G.711/G.722.1/G.726/MP2L2/PCM/ AAC-LC

Audio Input

Built-in Microphone, record with audio

Lens

4 mm

Min. Illumination

Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR

Angle of View

Horizontal FOV 78°, vertical FOV 38°, diagonal FOV 96°

Supplement Light Type

Smart Dual-Light, IR, White Light

Supplement Light Range

Up to 30 m

Motion detection 2.0

Supoort, include Human & Vehicle detection

Image Enhancement

BLC, HLC, 3D DNR

Wide Dynamic Range

120 dB WDR

Protocols

TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP

API

Open Network Video Interface Version (Profile S, Profile T, Profile G)

Region of Interest (ROI)

1 fixed region for main stream

Privacy Mask

4 programmable polygon privacy masks

General Function

Rotate mode, mirror, password protection, remote access

Ethernet

1 RJ45 10 M/100 M self-adaptive Ethernet port

General

Housing

Metal & Plastic

Color

White & Black

Storage

Built-in microSD/SDHC/SDXC Slot, up to 512 GB

Hardware Reset

Yes

Operating Power

DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W

Operating Temperature

-22 °F – 140 °F/-30 °C – 60 °C

Indoor/Outdoor Use

Indoor/Outdoor

Interface Protection

IP67

Dimension (L X W X H)

170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7")

Weight

0.6 lb./285 g

Video Compression

H.264+/H.264/H.265/H.265+/MPEG4

IP Video Input

8CH PoE

Video Output

HDMI up to 4K, VGA up to 1080p

Audio Input/Output

1/1 RCA

Incoming Bandwidth

80 M

Max Recording Resolution

Up to 8MP (3840 X 2160)

Max Playback Resolution

Up to 8MP (3840 X 2160)

Max Playback Channel

8CH

Max Playback Capacity

4-CH@1080p, 1-CH@8MP

ONVIF Protocols

Support

HDD

1 SATA Interface

HDD Capacity

Up to 6 TB Capacity for Each HDD

Network Interface

RJ45 X1 (10/100/1000 M)

PoE

8 Ports (IEEE802.3at/af)

Alarm Input/Output

-

RS485

-

USB

2X USB 2.0

Operating Power

DC 48 V

Power Consumption

≤10 W (Without HDD and PoE)

PoE: Max 25.5 W for Single Port

Working Temperature

14 °F ~ 131 °F/-10 °C ~+55 °C

Dimensions (W X H X D)

12.4' X 9.4' X 1.9'/315 X 240 X 48 mm

Weight (Without Hard Disk)

2.2 lbs./1 kg
