ANNKE 8CH Network POE Video System Home H.265+ Smart Dual Light Night Vision Motion Detection Security Camera Surveillance Kit
Key features
NVR:
· Live view, recording&playback up to 12 MP resolution
· Up to 8 channel IP cameras can be connected with built-in PoE inputs
· Advanced H.265+ Video Compression
· Supports iPhone, iPad, Android mobile remote monitoring
· Connectable to the third-party network cameras
· HDMI Video output at up to 4K (40960 × 2160) resolution
· Annke Vision for easy remote view
· Support 4-ch Human and vehicle targets detection
Camera
★ 3K IR Network Camera with 16:9 image scale
★ 2.8mm@F1.6 lens brings everything back to life
★ Efficient H.265+ compression technology
★ Motion detection 2.0 with human & Vehicle Detection
★ Smart Dual-Light: advanced technology with long range
★ Clear day and night vision with 3D DNR and 120DB WDR
★ Built-in microphone for real-time audio security
★ Support on-board storage up to 512 GB (SD card slot)
★ IP67 Dust and Waterproof Rating
★ Support PoE &DC12V
4K Ultra HD Live View & Record
This powerful NVR is able to record smooth real-time 4K videos on all 8 channels. If an incident occurs, 4K footages will offer the best chance to capture crystal & useful evidences.
Expandable ONVIF 4K Ultra HD NVR
*The NVR works with up to 8 ANNKE IP cameras & other ONVIF cameras, regardless bullet, dome or PTZ cameras.
*4K NVR is compatible with 1MP, 2MP, 3MP, 4MP, 5MP, 6MP, 7MP & 8MP (4K) IP cameras for unrivaled integration.
Quadruple Video Coding Options
*Quadruple H.264/H.264+/H.265/H.265+ coding allows for maximum encryptions with the latest tech & backwards compatibility with legacy platforms.
*H.265+ video format provides fast stream without latency, consumes less bandwidth and records longer videos than H.264 systems.
Customized Motion Areas & Privacy Mask
*Customize the vital areas, like front door, garage, to receive alerts only when motion events happen in these areas.
*Mask the private areas, such as windows, license plates to protect your privacy. The NVR will ignore the areas when recording videos 24/7.
Smart Motion Detection Alerts
*When there are motion events, you'll receive instant app pushes & email alerts and the buzzer alarms of the NVR.
*Access the NVR to check the motion events and take actions at once to deter intruders before intrusion.
4PCS
8PCS
NVR:
Video & Audio | Decoding Format | H.264+/H.264/H.265/H.265+ |
IP Video Input | 8CH PoE | |
Video Output | HDMI up to 4K (4096 × 2160), VGA up to 1080p(1920 × 1080) | |
Audio Input/Output | 1/1 RCA | |
Incoming/outgoing Bandwidth | 80/80 Mbps | |
Max Recording Resolution | Up to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) | |
Max Playback Resolution | Up to 12MP(4096 X 3072)@30fps(Frame rate depends on IP camera) | |
Max Playback Channel | 8CH | |
Max Playback Capacity | 1-ch@12 MP(4096 X 3072) (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps) | |
Hard Drive | HDD | 1 SATA Interface |
HDD Capacity | Up to 8 TB Capacity | |
External Interface | Network Interface | 1, RJ-45 10/100Mbps self-adaptive Ethernet interface |
PoE | 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface, IEEE 802.3 af/at | |
USB interface | USB 2.0*2 | |
Smart Function | Deep learning | 8-ch Human and vehicle targets detection(Need IP camera support) |
4-ch Human and vehicle targets detection(IP camera does not need to support this function but the resolution cannot exceed 4MP) | ||
Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting | |
General | Operating Power | DC 48 V |
Power Consumption | ≤10 W (Without HDD and PoE) | |
PoE: Max 25.5 W for Single Port | ||
Working Temperature | 14 °F ~ 131 °F/-10 °C ~+55 °C | |
Dimensions (W X H X D) | 12.4' X 9.4' X 1.9'/315 X 240 X 48 mm | |
Weight (Without Hard Disk) | 2.2 lbs/1 kg |
Camera:
Camera | Image Sensor | 1/3" Progressive Scan CMOS |
Max resolution | 3K(3072*1728), 16: 9 picture ratio is more suitable for the most popular display | |
Main Stream | 50 Hz: 20 fps (3072*1728), 25 fps ( 1920 X 1080, 1280 X 720) | |
Substream | 50 Hz: 25 fps (1280 X 720,640 X 480, 640 X 360) | |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 | |
Video Bitrate | 32 Kbps - 6 Mbps | |
Audio Compression | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC | |
Audio Input | Built-in Microphone, record with audio | |
Lens | 2.8 mm | |
Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR | |
Angle of View | Horizontal FOV 98°, vertical FOV 54°, diagonal FOV 114° | |
Supplement Light Type | Smart Dual-Light, IR, White Light | |
Supplement Light Range | Up to 30 m | |
Motion detection 2.0 | Supoort, include Human & Vehicle detection | |
Image Enhancement | BLC, HLC, 3D DNR | |
Wide Dynamic Range | 120 dB WDR | |
Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP | |
API | Open Network Video Interface Version 18.12 | |
Region of Interest (ROI) | 1 fixed region for main stream | |
Privacy Mask | 4 programmable polygon privacy masks | |
General Function | Mirror,rotate,password protection, remote access | |
Ethernet | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
General | Housing | Metal & Plastic |
Color | Black | |
Storage | Built-in microSD/SDHC/SDXC Slot, up to 512 GB | |
Hardware Reset | Yes | |
Operating Power | DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | |
Operating Temperature | -22 °F – 140 °F/-30 °C – 60 °C | |
Indoor/Outdoor Use | Indoor/Outdoor | |
Interface Protection | IP67 | |
Dimension (L X W X H) | 170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7") | |
Weight | 0.6 lb./270 g |
