ANNKE H800 8MP 4K Ultra HD PoE 8CH NVR Turret Security Camera System with 4pcs 4K Wired Outdoor Audio Recording Cameras
IP Camera | ||
Camera | Image Sensor | 1/2.4" Progressive Scan CMOS |
Max resolution | 3840*2160(8MP) | |
Main Stream | 50 Hz: 12.5fps@3840*2160, 20 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) | |
Substream | 50 Hz: 20 fps (1280 × 720, 640 × 480, 640 × 360) | |
Video Compression | Main stream: H.265+/H.265/H.264+/H.264 | |
Video Bitrate | 32 Kbps - 16 Mbps | |
Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM/ AAC-LC | |
Audio Input | Built-in Microphone, record with audio | |
Lens | 4 mm | |
Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR | |
Angle of View | Horizontal FOV 78°, vertical FOV 38°, diagonal FOV 96° | |
Supplement Light Type | Smart Dual-Light, IR, White Light | |
Supplement Light Range | IR: up to 30 m, white Light: up to 20 m | |
Motion detection 2.0 | Supoort, include Human & Vehicle detection | |
Image Enhancement | BLC, HLC, 3D DNR | |
Wide Dynamic Range | 120 dB WDR | |
Protocols | TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP | |
API | Open Network Video Interface Version (Profile S, Profile T, Profile G) | |
Region of Interest (ROI) | 1 fixed region for main stream | |
Privacy Mask | 4 programmable polygon privacy masks | |
General Function | Rotate mode, mirror, password protection, remote access | |
Ethernet | 1 RJ45 10 M/100 M self-adaptive Ethernet port | |
General | Housing | Metal & Plastic |
Color | White | |
Storage | Built-in microSD/SDHC/SDXC Slot, up to 512 GB | |
Hardware Reset | Yes | |
Operating Power | DC 12 V± 25%, max. 5 W; PoE (802.3af), max. 6.5 W | |
Operating Temperature | -22 °F – 140 °F/-30 °C – 60 °C | |
Indoor/Outdoor Use | Indoor/Outdoor | |
Interface Protection | IP67 | |
Dimension (L X W X H) | Ø110 mm × 89.2 mm (Ø4.3" × 3.5") | |
Weight | 0.7 lb./340 g | |
8CH NVR + 4Pcs Camera
