Hikvison 4K 8MP 16CH 16POE 1U POE AcuSense 4K NVR DS-7616NXI-I2/16P/S AcuSense Network Video Recorder Face Detect Surveillance

DS-7608NXI-I2/8P/S & DS-7616NXI-I2/16P/S
8/16-ch 1U 8/16 POE AcuSense 4K NVR
> H.265+/H.265/H.264+/H.264 video formats
> Intelligent analytics based on deep learning algorithm
> Up to 4-ch perimeter protection
> Up to 1-ch facial recognition for video stream
> Up to 4-ch facial recognition for face picture
> Up to 8/16-ch IP camera inputs
> Up to 16-ch 1080p decoding capability

Model: DS-7608NXI-I2/8P/S DS-7616NXI-I2/16P/S

Facial Recognition

Facial detection and

analytics:

Face picture comparison, human face capture, face picture search

Face picture library:Up to16face picture libraries,with up to 10,000 face pictures in total(eachpicture≤ 512 KB,

total capacity ≤150 MB)

Face picture comparison:4-ch face picture comparison alarm

Performance of facial

detection and analytics:1-ch human face capture (HD network camera, up to 8 MP, H.264/H.265)

Perimeter Protection

Human/Vehicle analysis:Up to 4-ch 2 MP (H.264/H.265) video analysis for human and vehicle recognition

to reduce false alarm

Video and Audio

IP video input:8-ch

:Up to 12 MP resolution

Incoming bandwidth:80 Mbps

Outgoing bandwidth:256 Mbps

HDMI output:4K(3840×2160)/60Hz,4K(3840×2160)/30Hz,2K(2560×1440)/60Hz,

1920×1080/60Hz,1600×1200/60Hz,1280×1024/60Hz,1280×720/60Hz,1024×768/60Hz

VGA output:1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz,

Video output mode:HDMI/VGA independent output

CVBS output:1-ch, BNC (1.0 Vp-p, 75Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480

Audio output:1-ch, RCA (Linear, 1 KΩ)

Two-way audio input:1-ch, RCA (2.0 Vp-p, 1 KΩ)

Decoding

Decoding format:H.265+/H.265/H.264+/H.264/MPEG4

Recording resolution:12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Synchronous playback:8-ch

Capability:16-ch@1080p (30 fps)

Dual stream recording:Support

Stream type:Video, Video & Audio

Audio compression:G.711ulaw/G.711alaw/G.722/G.726/MP2L2

Network

Remote connections:128

Network protocol:TCP/IP,DHCP,Hik-Connect, DNS, DDNS,NTP, RTSP,SADP, SMTP,SNMP,NFS, iSCSI,

ISUP, UPnP™, HTTP, HTTPS

Network interface:1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

PoE

Interface:8, RJ-45 10/100 Mbps self-adaptive Ethernet interface

Power:≤ 120 W

Supported standard:IEEE 802.3 af/at

Auxiliary interface

SATA:2 SATA interfaces supporting hot-plug

Capacity:Up to 8 TB capacity for each disk

Alarm in/out:4/1

USB interface:Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0

General

Power supply:100 to 240 VAC, 50 to 60Hz

Consumption(without HDD):≤ 15 W

Working temperature:-10 °C to 55 °C (14 °F to 131 °F)

Working humidity:10% to 90%

Chassis:1U chassis

Dimension (W × D × H):385 × 315 × 52 mm ( 15.2"× 12.4" × 2.0")

Weight (without HDD):≤ 2.7 kg (6.0 lb)

Certification

FCC:Part 15 Subpart B, ANSI C63.4-2014

CE:EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4
