SANNCE 4CH DVR CCTV System 4PCS 2MP IP66 Waterproof Outdoor Security Cameras 1080P TVI CCTV DVR 1280TVL Surveillance Kit
DVR | ||
Video & Audio | Codec | H.264+ |
Video input | 8*BNC | |
HDMI output | 1*HDMI (MAX:1080P) | |
VGA output | 1*VGA (MAX:1080P) | |
Audio I/O | 1/1 | |
Encode | 8*1080N@15fps | |
Decode | 4*1080N@15fps | |
Multi-mode | Analog: 8*1080N@15fps;4*5M-N(21fps) | |
Hybird: 8*1080N@15fps(analog)+2*1080P | ||
IP: 16*1080P；16*5MP | ||
Playback | 4CH (Analog mode) | |
Compression | G.711a | |
Intercom | Support | |
Hard Drive | HDD | 1*SATA interface |
HDD Capacity | Up to 8TB Capacity | |
Management | Record mode | Manual>Motion detection>Schedule |
Inquire mode | Inquire by Time/Calendar/Event/Channel | |
Storage mode | Sata HDD | |
Backup | Network, USB storage | |
External Interface | Ethernet port | 1*10/100Mbps Ethernet port, RJ45 port |
Alarm I/O | / | |
PTZ control | / | |
USB Port | 2*USB2.0 ports | |
General | Power supply | 12V/2A |
Consumption | <10W(Without HDD) | |
Temperature | 0℃- + 55℃ | |
Humidity | 10% -90% RH | |
Dimension | 255(L)* 236mm(W)* 44mm(H) | |
Weight | Around 1KG | |
HD Camera | ||
Camera | Video Resolution | HD 1080P |
Signal system | PAL/NTSC | |
Image sensor | Progressive Scan CMOS | |
Lens | 3.6mm | |
Min.Illumination | 0.02Lux@(F1.2 AGC ON),0Lux with IR on | |
Angle of View | 70° | |
Number of Infra-Red LEDs | 12 | |
Night Vision Distance | Up to 100ft/30m | |
DNR | DNR | |
Wide Dynamic Range | Digital WDR | |
IR Cut Filter | Yes | |
Video Output | HD BNCx1 | |
General | Housing | Plastic |
Color | White | |
Operating Power | DC12V | |
Operating Temperature | -40 °F – 140 °F /-40 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP66 | |
Dimension (L x W x H) | 6.49' x2.36' x 2.36' / 165 x 60 x 60mm | |
Weight | 0.33lbs / 150g | |
