SANNCE 8CH 1080P Lite DVR CCTV System 4/8pcs FD 2.0MP Security Cameras IR Outdoor IP66 Video Surveillance Kit Motion Detection
Note:
1.If you don't purchase a hard disk,you can't record and review the video.
2.If you purchase a package with a hard disk, the hard disk may be placed directly in the DVR or placed separately in the package. If you have any questions, please contact us.
3.Our 8CH DVR can connect 8 cameras max, so you can add extra cameras in the future.
Camera Key Features
★ TVI 1080P high clarity bullet camera
★ Up to 30m night vision with 12pcs IR leds
★ 3.6mm lens brings everything back to life
★ Clear day and night vision with auto IR-cut
★ IP66 Dust and Waterproof Rating
DVR Key Features
. Support 8CH 1080N definition encoding
. Support AHD, TVI,CVI, CVBS, IP video input
. HDMI/VGA simultaneous video output
. 1 SATA (Up to 8TB)
. 1*10/100Mbps auto-adaptive Ethernet port, RJ45 port
. Automatic networking support, a key to add equipment
. Support alarm information push to phone
. Support remote access, support ARSP
. Mobile phone remote monitoring (iOS, Android)
. Support Multi browser access, VMS PC client
4Pcs Camera Kits
8Pcs Camera Kits
DVR | ||
Video & Audio | Codec | H.264+ |
Video input | 8*BNC | |
HDMI output | 1*HDMI (MAX:1080P) | |
VGA output | 1*VGA (MAX:1080P) | |
Audio I/O | 1/1 | |
Encode | 8*1080N@15fps | |
Decode | 4*1080N@15fps | |
Multi-mode | Analog: 8*1080N@15fps;4*5M-N(21fps) | |
Hybird: 8*1080N@15fps(analog)+2*1080P | ||
IP: 16*1080P；16*5MP | ||
Playback | 4CH (Analog mode) | |
Compression | G.711a | |
Intercom | Support | |
Hard Drive | HDD | 1*SATA interface |
HDD Capacity | Up to 8TB Capacity | |
Management | Record mode | Manual>Motion detection>Schedule |
Inquire mode | Inquire by Time/Calendar/Event/Channel | |
Storage mode | Sata HDD | |
Backup | Network, USB storage | |
External Interface | Ethernet port | 1*10/100Mbps Ethernet port, RJ45 port |
Alarm I/O | / | |
PTZ control | / | |
USB Port | 2*USB2.0 ports | |
General | Power supply | 12V/2A |
Consumption | <10W(Without HDD) | |
Temperature | 0℃- + 55℃ | |
Humidity | 10% -90% RH | |
Dimension | 255(L)* 236mm(W)* 44mm(H) | |
Weight | Around 1KG | |
HD Camera | ||
Camera | Video Resolution | HD 1080P |
Signal system | PAL/NTSC | |
Image sensor | Progressive Scan CMOS | |
Lens | 3.6mm | |
Min.Illumination | 0.02Lux@(F1.2 AGC ON),0Lux with IR on | |
Angle of View | 70° | |
Number of Infra-Red LEDs | 12 | |
Night Vision Distance | Up to 100ft/30m | |
DNR | DNR | |
Wide Dynamic Range | Digital WDR | |
IR Cut Filter | Yes | |
Video Output | HD BNCx1 | |
General | Housing | Plastic |
Color | White | |
Operating Power | DC12V | |
Operating Temperature | -40 °F – 140 °F /-40 °C – 60 °C | |
Indoor/Outdoor | Indoor/Outdoor | |
Weatherproof Rating | IP66 | |
Dimension (L x W x H) | 6.49' x2.36' x 2.36' / 165 x 60 x 60mm | |
Weight | 0.33lbs / 150g | |
