SANNCE 8CH 5MN Video Recorder Support AHD, TVI,CVI, CVBS, IP video input 5MP 5 IN 1 DVR For 2MP 3MP 4MP 5MP Cameras
Key features
. Support 8CH 5MN definition encoding
. Support AHD, TVI,CVI, CVBS, IP video input
. HDMI/VGA simultaneous video output
. 1 SATA (Up to 8TB)
. 1*10/100Mbps auto-adaptive Ethernet port, RJ45 port
. Automatic networking support, a key to add equipment
. Support alarm information push to phone
. Support remote access, support ARSP
. Mobile phone remote monitoring (iOS, Android)
. Support Multi browser access, VMS PC clie
Up to 5MP Ultra HD Live View
The hybrid digital video recorder supports 5MP cameras to provide you with 5MP streaming and 5MP lite recording, bring everything to life with stunning and clear details, even the license plate can be recognized easily.
Powerful 5-in-1 DVR
SANNCE versatile 8-channel hybrid DVR supports up to 12CH with 8CH 5MP TVI, AHD, CVI, CVBS analog cameras and 4CH 2MP IP cameras simultaneously, regardless bullet, turret, dome, PTZ camera types. You may integrate any type of security camera you want for 24/7 non-stop recording.
24/7 Security in Your Hand
You are allowed to access the DVR system via the app on you phones to to watch high-clarity live stream any time you like. Always stay connected to your home and family, no matter you are in the work or on the journey.
Smart Motion Alerts & Remote Access
With the advanced motion detection algorithm, the DVR detects any difference and sends real-time app push notifications and email alerts to you. Control the DVR remotely via 3G/4G/5G or WiFi through your smartphones, tablets, computers, laptops and IE browser.
Compatible H.264+ Video Format
H.264+ coding saves more videos and consumes less bandwidth than H.264 systems. It is the most compatible video compression technology that provides you with ultra-smooth 5MP Lite streaming without all the data.
DVR | ||
Video & Audio | Codec | H.264+ |
Video input | 8*BNC | |
HDMI output | 1*HDMI (MAX:1080P) | |
VGA output | 1*VGA (MAX:1080P) | |
Encode | 8*5MN@15fps | |
Decode | 4*5MN@15fps | |
Multi-mode | Analog: 8*5MN@15fps; | |
Hybird: 8*5MN@15fps(analog)+4*1080P | ||
IP: 16*1080P；16*5MP | ||
Playback | 4CH (Analog mode) | |
Compression | G.711a | |
Intercom | Support | |
Hard Drive | HDD | 1*SATA interface |
HDD Capacity | Up to 8TB Capacity | |
Management | Record mode | Manual>Motion detection>Schedule |
Inquire mode | Inquire by Time/Calendar/Event/Channel | |
Storage mode | Sata HDD | |
Backup | Network, USB storage | |
External Interface | Ethernet port | 1*10/100Mbps Ethernet port, RJ45 port |
Alarm I/O | 0/0 | |
PTZ control | 1*RS485, Support for multiple PTZ protocol | |
USB Port | 2*USB2.0 ports | |
General | Power supply | 12V/2A |
Consumption | <10W(Without HDD) | |
Temperature | 0℃- + 55℃ | |
Humidity | 10% -90% RH | |
Dimension | 255(L)* 236mm(W)* 44mm(H) | |
Weight | Around 1KG | |
